多相控制器 / 2路 / 11-15相

·       Native Trans-Inductor Voltage Regulator (TLVR) Support

-        No external passive components required

·       Built-in 1kΩ current sense resistor

·       Paired with IPGSemi Smart Power Stages or Modules for high density solutions

·       Scalability and Flexibility

-        Scalable phase count: (12+0) to (8+4)

-        Flexible phase order assignment

·       Input and Output Range, Accuracy

-        4.5V to 16V input & 0.2V to 2.8V output

-        0.5% accurate output with differential sense

·       Telemetry

-        1.5% Input & Output voltage accuracy

-        1.5% Output current accuracy

-        +/-2°C Temperature accuracy

·       Improved Performance

-        Improved efficiency: Programmable Auto phase add/drop thresholds for optimization

-        Programmable Over-shoot & Under-shoot Reduction thresholds for better transient

-        Thermal Balance Management

·       Protection Capability

-        Programmable Fault Response: Latch & Hiccup

-        UVLO, UVP, OVP, OCP, OTP

-        Cycle by cycle per-phase current limit

·       Output BOM, Platform Area and Cost Reduction

-        Up to 4MHz switching frequency & Constant On Time control with fast transient for smaller & low-cost external passives

-        Programmable DC load line helps reduce the overshoot and the external capacitors

·       Ease-of-use, Interfaces and Debug Features

-        Internal compensation

-        Intel VR14/VR13.HC/VR13 Compliant

-        PMBus™ v1.3.1 Compliant

-        Built in Multiple time Programmability (MTP) with up to 32 writes for field programmability

-        Black box registers for fault record

·       RoHS Compliant and Green

·       6 mm × 6 mm, 48-Pin, QFN Package
