总线转换器（IBC） / 固定电压 / 48V
PM67594
PM67594
• 40 to 60V Input Voltage Range
• 12V Regulated Output Voltage
• Up to 1300W Continuous Output Power
• Up to 2000W Transient Output Power
• Up to 98.3% Efficiency
• Parallel Operation for Multi-kW Arrays
• Configuration and Monitoring via PMBus
• 58.4mm x 36.8mm x 12.7mm
• Wave and Reflow Soldering (MSL3)
• UL62368-1, 2nd Pending.
• Artificial Intelligence System
• Data Center
• Computing systems
The PM67594 is a high-efficiency, non-isolated power module.
The module operates from a 40V to 60V DC primary input voltage bus and outputs a 12V regulated DC voltage. It can deliver up to 1300W continuously and 2000W in transient.
The built-in digital controller can store and restore module configurations. The fault status, input voltage, output voltage, output current, and temperature are monitored via the PMBus interface.
The PM67594 is available in a quarter-brick (58.4mm x 36.8mm x 12.7mm) package.
| P/N | Vin (V) | Conversion Ratio | TDP | Package | status |
|---|---|---|---|---|---|
| PM67594R | 40 - 60 | 1/4 Brick | 1300W | QB 58.4 x 36.8 x 12.7mm | Active |
