总线转换器（IBC） / 固定电压 / 48V
PM67596
PM67596
• 40 to 60V Input Voltage Range
• 12V Regulated Output Voltage
• Up to 1600W Continuous Output Power
• Up to 2400W Transient Output Power
• Up to 98.3% Efficiency
• Parallel Operation for Multi-kW Arrays
• Configuration and Monitoring via PMBus
• 58.4mm x 36.8mm x 12.7mm
• Wave and Reflow Soldering (MSL3)
• UL62368-1, 2nd Pending.
• Artificial Intelligence System
• Data Center
• Computing systems
The PM67596 is a high-efficiency, non-isolated power module.
The module operates from a 40V to 60V DC primary input voltage bus and outputs a 12V regulated DC voltage. It can deliver up to 1600W continuously and 2400W in transient.
The built-in digital controller can store and restore module configurations. The fault status, input voltage, output voltage, output current, and temperature are monitored via the PMBus interface.
The PM67596 is available in a quarter-brick (58.4mm x 36.8mm x 12.7mm) package.
| P/N | Vin (V) | Conversion Ratio | TDP | Package | status |
|---|---|---|---|---|---|
| PM67597R | 40 - 60 | 4:1 | 1000W | LGA 23 x 17.4 x 7.6mm | Active |
